Tool Holder: SDS-Plus
Battery chemistry: XR Li-Ion, Voltage: 18 V
Battery Capacity: 5.0 Ah, Power Output: 400 Watt
Impact energy (EPTA 05/2009): 2.1 J
No Load Speed: 0-1100 rpm, Blows per Minute: 0-4600 bpm
Max. Drilling Capacity [Concrete]: 24 mm
Max. Drilling Capacity [Wood]: 26 mm
Max. Drilling Capacity [Metal]: 13 mm
Weight: 3.1 kg, Length: 301 mm, Height: 202 mm, Width: 85 mm
Hand/Arm Vibration – Hammer drilling into concrete: 6.6 m/s²
Uncertainty K 1 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Chiselling: 5.4 m/s²
Uncertainty K 2 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Drilling into metal: <2.5 m/s²
Uncertainty K 3 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Screw driving without impact: <2.5 m/s²
Uncertainty K 4 (Vibration): 1.5 m/s²
Sound Pressure: 86 dB(A), Sound Pressure Uncertainty: 3 dB(A)
Sound Power: 97 dB(A), Sound Power Uncertainty: 3 dB(A)
