High power; durable motor delivers excellent power even at a maximum depth of cut
Stable block construction for low vibration running and long service life
Spindle lock for ease of blade change
Optimum balance for fatigue-free operation
Additional handle for two-handed work
Steel shoe for added durability
Protection hood for sawdust extraction
Variable adjustment of the mitre angle to 45° for added versatility Power Input: 1750 Watts
No Load Speed: 4700 rpm
Blade Diameter: 235 mm
Blade Bore: 30 mm
Bevel Capacity: 45°
Max. Depth of Cut at 90§: 86 mm
Max. Depth of Cut at 45§: 62 mm
Weight: 8.2 kg
Length: 430 mm
Height: 290 mm
Hand/Arm Vibration: 2.5 m/s²
Uncertainty K 1 (Vibration): 1.5 m/s²
Sound Pressure: 99 dB(A)
Sound Pressure Uncertainty: 3 dB(A)
Sound Power: 110 dB(A)
Sound Power Uncertainty: 3 dB(A)
