Tool Holder: SDS-Plus
Power Input: 1000 Watts
Power Output: 450 Watt
Impact energy (EPTA 05/2009): 4.2 J
No Load Speed: 0-820 rpm
Blows per Minute: 0-4700 bpm
Max. Drilling Capacity [Concrete]: 32 mm
Max. Drilling Capacity [Core bit]: 100 mm
Max. Drilling Capacity [Wood]: 32 mm
Max. Drilling Capacity [Metal]: 13 mm
Weight: 4.2 kg
Length: 370 mm
Height: 250 mm
Width: 85 mm
Hand/Arm Vibration – Hammer drilling into concrete: 8.2 m/s²
Uncertainty K 1 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Chiselling: 7.1 m/s²
Uncertainty K 2 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Drilling into metal: <2.5 m/s²
Uncertainty K 3 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Screw driving without impact: <2.5 m/s²
Uncertainty K 4 (Vibration): 1.5 m/s²
Sound Pressure: 86 dB(A)
Sound Pressure Uncertainty: 3.0 dB(A)
Sound Power: 97 dB(A)
Sound Power Uncertainty 3 dB(A)
