Tool Holder: SDS-Max
Power Input: 1500 Watts
Power Output: 980 Watt
Impact energy (EPTA 05/2009): 15.5 J
Load Speed: 125-250 rpm
Blows per Minute: 1150-2300 bpm
Max. Drilling Capacity [Concrete]: 52 mm
Max. Drilling Capacity [Breakthrough bit]: 80 mm
Max. Drilling Capacity [Core bit]: 150 mm
Weight: 9.9 kg
Length: 561 mm
Height: 272 mm
Width: 116 mm
Hand/Arm Vibration – Hammer drilling into concrete: 8.0 m/s²
Uncertainty K 1 (Vibration): 1.5 m/s²
Hand/Arm Vibration – Chiselling: 7.2 m/s²
Uncertainty K 2 (Vibration): 1.5 m/s²
Sound Pressure: 96 dB(A)
Sound Pressure Uncertainty: 3 dB(A)
Sound Power: 107 dB(A)
Sound Power Uncertainty: 4 dB(A)
