Guide lubrication system: guide internal storage design, which can make the guide parts has been in the lubrication state, prolong the service life of guide rail
Load rpm:250/450rpm
Motor rated power:1500W
Tool holder:MT3
Voltage:220V~240V
Frequency range:50~60Hz
Magnetic adhesion:15000N
Max.cutting dia(Hss annular cutter):50mm/1-15/16”
Max cutting dia(TCT annular cutter):60mm(2-3/8”)
Max.cutting dia(Twist drill):32mm/1-1/4”
Max.cutting depth:75mm/3”
Stroke:170mm
Magnet footprint:210mmX100mmX45mm
Weight:19Kg
